Electric Table Truck 1KG=2.2LB 1INCH=25.4MM
TYPE   ETF30 ETF50 ETF75
Capacity kg 300 500 750
Max.table height h2 mm 880 1025 970
Min.table height h1 mm 290 440 420
The Dimension of Table Size(L*B) mm 850×500×50 1010×520×50 1000×510×55
Caster Wheel d mm Φ125×40 Φ150×48 Φ147×50
Overall length L1 mm 1145 1305 1345
Height Of Handle From The Ground h3 mm 920 970 935
Lifting speed with load/without load mm/s 65/94 65/94 70/80
Lowering speed with load/without load mm/s 98/74 98/74 50/35
Lifting Cycle(fully charged)   120 100 100
Battery × 2   12v21Ah 12v21Ah 12v 24Ah
Vertical Travel h4 mm 590 585 550
Lifting Motor(DC24V KW)   0.8 0.8 0.8
Charger(built-in)24V4A   8.5Hr 8.5Hr 8.5Hr
Approx Lifting Speed s 10 10 10
Net Weight kg 115 157 160
